EtherHaul Kilo Series
The Siklu by Ceragon EtherHaul™ Kilo Series products are the most widely deployed 70/80GHz radios in the world. This is due to the fact that not only was Siklu by Ceragon first in offering advanced mmWave products to the market at attractive prices, we also continue to deliver best in class solutions. Our radios are unmatched in performance and reliability, delivering multi-Gbps connections over unprecedented distances.
- Award-winning Solutions
- World-class Support
70/80GHz Radios: Robust, Future-proof Connectivity to Extend your Reach and Save on CAPEX
Capacities start at 700Mbps TDD with the EH-1200TX product and go as high as 10Gbps Full Duplex with the FDD EH-8010. With Siklu’s patented RFIC implementations these capacities are supported at ranges reaching as far as 4.3 miles (6.9km) and at a cost that has led and dramatically expanded the market for gigabit connectivity in the E band spectrums.
Similar to the V band or 60GHz products, the EtherHaul Kilo Series supports wide frequency agility in the 70/80GHz bands and extremely narrow beams resulting in almost unlimited spectrum for dense deployments of EtherHaul radios.
Carrier Class Construction and Performance
- Small form factor, all-outdoor IP67 rated system
- Up to 10Gbps full duplex throughput over ranges as far as 10 miles (16km)
- Field proven advanced all-silicon integration yields a high 90-yr MTBF
- Real time connectivity with <10usec latency supports the most demanding delay sensitive applications
- Optional integrated timing over packet 1588v2 facilitate reliable, accurate mobile backhaul synchronization
- Prioritized payloads using hitless adaptive modulation synced with 8 levels of QoS.
- Leading in-class RF performance coupled with lowest power consumption per Gbps
EtherHaul Kilo Radios
All of Siklu’s R&D results in a product family delivering multi Gigabit throughputs for mobile backhaul, network backbones and fiber extensions at prices and distance that can’t be beat.
Installation Guide
Consult with Ceragon's Experts
Scoping a project and want to consult our team? Scope, design and plan your next project with Ceragon. Contact us today.
Product Reference Guide
- mmWave Overview
- Solutions Categories Breakdown
- Complete Solutions Technical Specifications
Spectrum Agility
- Interference-free operation in the 70/80GHz band with TDD or FDD support
- Up to 10GHz of available spectrum in the 70/80GHz bands, pencil width beams with tiny Fresnel zone and up to 32 non-overlapping, user-selectable channels yield the industry’s highest spectrum re-use factor.
- One SKU supports the entire range in the 70/80GHz band
Want to learn more?
Flexible Topology and Interfaces
- Advanced networking toolkit to create flexible topologies in chains, drop & insert and sub-50msec resilient rings
- Designed for easy installation and commissioning using embedded tools to optimize channel selection, load testing and zero-touch commissioning
- With layer 2 support via a built-in Gigabit switch with extra copper and fiber ports enables seamless cascading
- PoE out for external powering of cameras and other devices
- MEF-compliant Ethernet OAM and CFM (IEEE 802.1ag / ITU-T Y.1731 / IEEE 802.3ah) for advanced monitoring and troubleshooting.
